SMC Networks Prime-600 User Manual

User Guide
17
Prime – 600 (A first glimpse of the console).
1
Indicates which USB port is active
2
Date and time
3
Disconnected measurement connections indicator
4
Test start / stop button
5
Print out test
6
Save test
7
Indicates the selected current injection
8
Indicates the selected work mode
2
7
8
10
14
3
4
5
6
9
11
12
13
1
