User Guide
39
5. Access the current injection menu.
Enter the current value that adapts to the device tested.
You can set up the “Dual Ground Clamp” functionality. This
functionality will be explained in detail later on in this manual.
6. Access the resistance range menu.
We recommend using the “Auto” mode as better precisions can be
obtained, although the resistance range to be measured can also
be set.
Steps to be followed to perform the test:
1. Connect the crocodile clips of the high current cables to the current taps of
the device tested.
2. Connect the voltage measurement cables to the appropriate sensing
connections of the device tested.
3. Start the test by pressing .
a. The start of injection will be indicated with two beeps and the
current injection indicators will be activated.
b. The end of the first measurement will be indicated with one beep
and the current injection indicator on the console will go off
c. Once the time set in the “Waiting Time” has passed, the
equipment will carry out a current injection again and its
subsequent measurement, and the current injection indicator on
the console will once again be activated
d. The sequence will be repeated as often as set by the user in
the “Seq. Num” parameter.
