SPECIFICATIONS
Prime – 600.
STATIC RESISTANCE
MEASUREMENT
Sample Rate (Max.): 30 kSPS – Temp.: 10 ~ 40ºC
RANGE
RESOLUTION
PRECISION
1000.0µΩ
0.1µΩ
10.0µΩ < R ≤ 100.0µΩ (150 ~ 600A): ± 0.3µΩ
100.0µΩ < R ≤ 1000.0µΩ (20 ~ 600A): ± 0.2% ® ± 0.1µΩ
10,000mΩ
1µΩ
1,000mΩ < R ≤ 10,000mΩ (5 ~ 600A): ± 0.2% ® ± 0.001mΩ
100.00mΩ
10 µΩ
10.00mΩ < R ≤ 100.00mΩ ( 5 ~ 600
(*)
A): ± 0.2% ® ± 0.01mΩ
1000.0mΩ
100 µΩ
100.0mΩ < R ≤ 1000.0mΩ (5 ~ 60
(*)
A): ± 0.2% ® ± 0.1mΩ
(*) : Ó 6000/R(mΩ), whichever is less.
DYNAMIC RESISTANCE
MEASUREMENT
Sample Rate (Max.): 30 kSPS – Bandwidth: 2,5 KHZ - Temp.: 10 ~
40ºC
10.00mΩ
10 µΩ
0.10mΩ < R ≤ 1.00mΩ (5 ~ 600A): ± 0.01mΩ
1.00mΩ < R ≤ 10.00mΩ (5 ~ 600A): ± 0.2% ® ± 0.01mΩ
100.0mΩ
100 µΩ
10.0mΩ < R ≤ 100.0mΩ ( 5 ~ 600
(*)
A): ± 0.2% ® ± 0.1mΩ
1000mΩ
1000 µΩ
100mΩ < R ≤ 1000mΩ (5 ~ 60
(*)
A): ± 0.2% ® ± 1mΩ
(*) : Ó 6000/R(mΩ), whichever is less.
CC INJECTION – WORK CYCLE
5…600 Acc / 2s
5…300 Acc /
2min
5…150 Acc / perm
CC INJECTION – RESOLUTION
1 Acc
CC INJECTION – MINIMUM VOLTAGE (@V.line: 120/240 Vac)
6 Vcc to 600A
RESULTS MANAGEMENT
Storage
Internal memory and USB external memory
Communications
Type B USB connection
Reports
Software for PC Windows supplied with equipment
GENERAL
Power supply
115/230 Vac (automatic detection) / 50-60 Hz. Fuse
Dimensions
47 x 35.7 x 17.6 cm / 13.3 kg
Box
In ABS with IP67 protection degree
Temperature
Operation: 0…50ºC / Storage: -25…70ºC
