Prime - 600
42
ADVANCED SETTINGS
Dual Ground Clamp”
The Prime - 600 permits working with dual grounding. This system measures
the part of the current that circulates through the ground circuit and eliminates it
accurately and instantaneously from the calculation of the resistance. It enables
the test to be performed pursuant to safety standards and without compromising
the safety of the operators or the facility.
Setting:
1. Connect the high current cables to the current taps of the Prime - 600.
2. Connect the measurement cables to the voltage measurement
connections of the Prime - 600.
3. Connect the cables of the ammeter clamp to the “Clamp” connections of
the Prime - 600.
a. We recommend using the ammeter clamp supplied by EuroSMC
as an optional accessory.
b. A direct current measurement ammeter clamp can also be used
and its output will be given in direct voltage.
4. Turn on the equipment.
5. Access the injection setup menu.
The accessories used in these settings are optional, supplied by
EuroSMC.
