User Guide
19
HOW TO CONNECT THE SYSTEM
The Prime system will be comprised of at least a couple of high current cables, a
couple of voltage measurement cables and a couple of crocodile clips.
Making the connections.
Before continuing, make sure that the on/off switch of the unit is in its
Disconnected position.
Make the necessary connections both for injection and measurement. These will
vary depending on the nature of the test and in some cases we will describe
them later on in this manual.
Connect the power cable supplied to 120Vac or 230Vac
The power supply used must have ground tap.
Bear in mind that the longer the high current path is, the
maximum injectable values may suffer limitations.
We recommend the measurement cables being connected as
close as possible to the device tested, and as close to each
other as possible.
