Prime ‐ 600: Typical High Current D.C. Power Output (English only).
Line Supply
(V.a.c,F=50Hz)
High Current Connection Leads
I out
(A)
V load
Max.(V)
R load
Max.(mΩ)
R Measurable
Max.(mΩ)
120
Standard 2x3m/35mm
2
High Flexibility Crocodile
Finished.
5
12.33
2465
1000
150
10.18
67.9
40.0
300
7.97
26.6
20.0
600
3.54
5.90
5.90
240
5
13.54
2708
1000
150
11.87
79.1
40.0
300
10.13
33.8
20.0
600
6.67
11.12
10.00
120
Optional 2x6m/35mm
2
High Flexibility Crocodile
Finished.
5
12.31
2462
1000
150
9.65
64.3
40.0
300
6.90
23.0
20.0
600
1.41
2.34
2.34
240
5
13.52
2705
1000
150
11.33
75.6
40.0
300
9.07
30.2
20.0
600
4.54
7.56
7.56
120
Optional 2x10m/35mm
2
High Flexibility Crocodile
Finished.
5
12.28
2457
1000
150
8.94
59.6
40.0
300
5.48
18.3
18.3
535.0
0.06
0.12
0.12
240
5
13.50
2700
1000
150
10.62
70.8
40.0
300
7.65
25.5
20.0
600
1.70
2.83
2.83
Remarks :
* High Current Cables & Prime ‐ 600 at 23ºC +/‐ 2ºC.
* Injection Current ON Time ≤ 2S (1 Test with Prime ‐ 600 & Current Cables from cold condition)
* Line Supply Voltage is in V.r.m.s under loaded condition.
* Values Shown are Typical Values based on the following approximation derived from real measured
values:
- High Current Output No Load Voltage & Output Resistance = 12.4V/10,9mOhms@Vline=120V.a.c.
- High Current Output No Load Voltage & Output Resistance = 13.6V/7,68mOhms@Vline=240V.a.c.
* Values Shown for Maximum Measurable Resistance are based on the following Specified Limits:
- Voltage at Load to be measured ≤ 6,000 Vdc (V sense input specification).
- Resistance to be measured ≤ 1,000 Ω (Highest Resistance Measurement Range specification).
