User Guide
31
5. Access the current injection menu.
Enter the current value that adapts to the device tested.
You can set up the “Dual Ground Clamp” functionality. This
functionality will be explained in detail later on in this manual.
6. Access the resistance range menu.
We recommend using the “Auto” mode as better precisions can be
obtained, although the resistance range to be measured can also
be set.
Steps to be followed to perform the test:
1. Connect the crocodile clips of the high current cables to the current taps of
the device tested.
2. Connect the voltage measurement cables to the appropriate sensing
connections of the device tested.
3. Perform the test by pressing .
Result:
Once you have successfully finished the test, the result will be shown on the
main screen and you may:
The equipment will indicate start of current injection with two
beeps and the end with one beep.
For greater safety, the Prime – 600 does not take the test as
finalised until the load is demagnetised.
