5. Access the current injection menu.
 Enter the current value that adapts to the device tested.
 You can set up the “Dual Ground Clamp” functionality. This
functionality will be explained in detail later on in this manual.
6. Access the resistance range menu.
 We recommend using the “Auto” mode as better precisions can be
obtained, although the resistance range to be measured can also
be set.
Steps to be followed to perform the test:
1. Connect the crocodile clips of the high current cables to the current taps of
the device tested.
2. Start the test by pressing .
3. Connect the voltage measurement cables to the appropriate sensing
connections of the device tested.
a. The equipment will automatically detect the connection
b. The start of injection will be indicated with two beeps and the
current injection indicators will be activated.
c. The end of the measurement will be indicated with one beep and
the current injection indicator on the console will go off.
d. Disconnect the measurement cables.
4. Connect the voltage measurement cables, in the next adequate sensing
connection of the device tested
a. The process described in point 3 will be repeated.
The red indicator, Out will remain on until the test sequence
ends.
