Data Manager Operations Scanner DataViewer Operation
Slider / Scroll Bars and Cursor
Use the slider bar to quickly navigate through the data (Figure 12-26). During playback the
number displayed on the left side of the slider bar indicates the current position of the cursor in the
data file. The cursor can be repositioned during playback or when paused, by selecting and
dragging.
Use the scroll bar (right side) to vertically scroll through the parameter list and graphs.
1— Cursor
2— Scroll bar
3— Slider bar
Figure 12-26
