47
Scanner Function Scanner Operation
Codes Menu
This selection may appear as Codes, Codes Menu, Codes Only, Codes (No Data), or something
similar on the menu. Selecting opens a list of data parameter viewing options that may include:
Display Codes
Selecting opens either a list of diagnostic trouble codes (DTCs) stored in the selected electronic
control module (ECM), or a submenu of DTC viewing options. Submenu options may include:
Trouble Code Information—opens a list of codes in ECM memory.
History Codes—opens a list of codes whose symptoms are not currently present. History
codes indicate an intermittently occurring problem.
Failed This Ignition—opens a list of codes that set during the current ignition cycle.
MIL SVS or Message Requested—displays ECM requests to light the malfunction indicator
lamp (MIL) or service vehicle soon (SVS) lamp, or display a driver information alert.
Last Test Failed—displays a complete list of failed tests.
Test Failed Since Code Cleared—displays a list of tests that failed since the last time codes
were cleared from ECM memory.
If SureTrack
®
(optional) is active and data is available for a selected DTC, additional
troubleshooting information from SureTrack (e.g. Common Replaced Parts data (Figure 4-24),
Real Fix and Related Fixes) will also be available. For additional information about using
SureTrack, see SureTrack on page 177.
A code list includes the DTC, a brief description, and a SureTrack Fix It! icon that opens a
submenu allowing you additional information about the DTC (Figure 4-24).
Figure 4-24 Sample code list and SureTrack information
