4�3 Checking the delivery for completeness
Check the contents of the delivered package for completeness and possible damage. In
the case of an inadequate delivery, please contact your dealer or the SolarMax Service
Center.
Gerätedokumentation
SolarMax HT-Serie
30HT4 / 32HT4
2
3
4
5
6
7
8
9
10
11
12
13
1
14
15
16
17
Figure 4 Content of delivery
No� Quantity Description
1 1 Inverter
2 1 Instruction manual
3 16 Locking clip (for locking the DC connector)
4 2 Safety brackets (for installation of inverter)
5 1 6-pole connector (for connection of status signaling contacts)
6 1 4-pole connector (RS485 connection)
7 1 3-pole connector (connection of external grid monitoring)
