16
No� Quantity Description
8 3 Locking pins (for multiple cable gland)
9 1 M5 toothed washer (connection of second protective conductor)
10 1 M5 cable shoe (connection of second protective conductor)
11 1 M5 circlip (connection of second protective conductor)
12 1 M5 washer (connection of second protective conductor)
13 1 M5 nut (connection of second protective conductor)
14 8 10 x 50 wall plugs (mounting of inverter)
15 8 M6 x 18 washers (mounting of inverter)
16 8 6 x 60 Torx pan head screws (mounting of inverter)
17 1 Mounting plate (mounting of inverter)
4�4 Selecting the installation location
DANGER!
Fatal re or explosion hazard!
The inverter is an electrical device with heat generation and the possibility of
sparking.
Install the inverter in an environment that is free of ammable gases and
uids.
Never install the inverter near combustible materials. The installation sub-
strate must be non-combustible.
Follow the local re safety regulations.
CAUTION!
Risk of injury - the inverter is heavy!
The inverter weighs approx. 70 kg.
The installation substrate must have sufcient structural strength.
Location and installation conditions
The ambient conditions are specied in the specications, see Section 11.
Select a dry location protected from water and snow.
Do not expose the inverter to direct sunlight.
Install the inverter in an easily accessible location, so that maintenance work can be
carried out easily.
When mounting the unit observe the following minimum distances:
