4. Pull out the DC input conductors to fully disconnect the inverter from the PV
generator.
5. Remove the cover of the inverter as described in Section 5.1.
6. Use a suitable voltage detector to check that all terminals are free from voltage.
– When all terminals are free from voltage you can remove the AC input conductor
and all communication cables.
7. Fit the cover of the inverter.
8. Remove the two safety brackets.
CAUTION!
Risk of injury - the inverter is heavy!
The inverter weighs approx. 70 kg.
Never dismount the inverter on your own.
9. When dismounting the inverter, ask a second person to help.
10�3 Disposing of the inverter
Dispose of the inverter as indicated by the local waste disposal regulations. You can also
return the inverter, at your own cost, to Sputnik Engineering AG for professional disposal.
The contact details of the SolarMax Service Center can be found on the back of this
instruction manual.
