SolarMax SM30HT4 - MaxTalk Measured Values; MaxView Registration

50
– Measured values under "Power unit 2":
Measured value Description Unit
Vdc 1, Vdc 2
Input voltage at MPP tracker 3 / MPP tracker 4 V
Idc1, Idc2
Input current at MPP tracker 3 / MPP tracker 4 A
Pdc
Input power (total of MPP trackers 3 and 4) W
Temperature
Cooling element temperature (MPP trackers 3 and 4) °C
4. Press to return to the Main Menu.
Note
The measured inverter values are not suitable for billing purposes or calcu-
lating the efciency. The measuring error may amount to up to ±5% depending
on the measured value. Only the measured values of a calibrated electricity
meter can be relied upon for billing purposes.
MaxTalk measured values
The MaxTalk 2 service software can be used to display, in addition, the following mea-
sured values of the inverter:
Measured value Description Unit
Vac 10 min 10 minute mean value of the mains voltage V
Iac mean Mean value of output current A
Ierr Ground leakage current mA
Ierr DC Leakage current mA
6�7 Registering for MaxView
Register for the free web-based MaxView application. As well as facilitating an optimum
after-sales service, MaxView enables you to display and graphically visualize the yield
data of your PV power plant from anywhere.
Note
Frequently asked questions about MaxView and the replies to these can be
found on our website at https://maxview.solarmax.com/faq.xhtml.
Procedure
1. Connect the inverter to the internet via the Ethernet interface (see Sections 5.5 and
6.4.3).
2. Enter your registration data in a web browser under https://maxview.solarmax.com.
3. Learn about the various functions of MaxView.
