SolarMax SM30HT4 - Status Signaling Configuration; Configuration Data Display

en
41
6�4�4 Conguring the status signaling contacts
The two status signaling contacts for the remote monitoring of the inverter can be con-
gured in four different ways.
Procedure
1. In the "Settings" menu, select the "Status relay" parameter.
2. Make the required setting:
Setting Description
Off The status signaling contacts are always open.
Grid When the inverter starts mains operation, the status signaling con-
tacts close and remain closed for as long as the inverter feeds into
the grid. When a power unit (MPP tracker 1/2 or MPP tracker 3/4) is
disconnected from the grid, the respective status signaling contact
opens after an adjustable delay time.
Error When a warning, a failure or a device error occurs at a power unit
(MPP tracker 1/2 or MPP tracker 3/4) (error messages, see Section
8.2), the respective status signaling contact closes after the expiry
of the adjustable delay time. The status signaling contact opens
when the error has been eliminated (factory setting).
On When a power unit (MPP tracker 1/2 or MPP tracker 3/4) switches
on when the DC input voltage is sufciently high, the respectie
status signaling contact closes. The status signaling contact opens
when the power unit switches off due to insufcient DC input
voltage.
3. Select the "Status relay delay" parameter.
4. Adjust the required delay time for the status signaling contacts:
Parameter Description Value range Unit
Status relay delay Delay time of status signaling contact 0 to 99 min
6�5 Displaying the conguration
All available operating parameters, standard-specic functions and their parameteriza-
tion can be retrieved in the "Conguration" menu. Conguration of the standard-specic
functions depends on the country setting selected.
Note
The MaxTalk 2 Pro service and communication software makes it possible
for authorized personnel to individually adjust the operating parameters (see
Section 12).
