Status of LED Operating status Description
Flashes red
Blocked
Inverter is blocked → grid disconnection
The "Failure", "Error", and "Blocked" operating status messages, as well as the warn-
ings, usually require certain actions to be carried out by the qualied electrician in charge
(see Section 8).
7�7�1 "Booting" operating status
Status LED: ashes green
Status message Description
No response The specied power unit (MPP tracker 1 / 2 or MPP tracker 3 / 4)
does not respond. The cause could be insufcient solar irradiation.
The inverter uses the available MPP tracker to feed into the grid.
Irradiation too low The solar irradiation or rather the available output is too low for
mains operation.
Start-up… The inverter checks the internal hardware and software compo-
nents before connecting to the mains.
Restart delay The inverter delays connection to the grid (after a disconnection
from the grid or when booting).
7�7�2 "Mains operation" operating status
The status LED lights up green.
Status message Description
Maximum output power The inverter limits the in-feed power to the maximum possible
value. This may occur if the PV generator is oversized.
Mains operation The inverter is in feed mode.
Idc limitation The inverter limits the PV generator current to the maximum per-
missible value. This may occur if the PV generator is designed such
that the current at the Maximum Power Point (MPP) exceeds the
maximum permissible input current of the inverter.
Iac limitation The inverter limits the output power to the maximum permissible value
(where the PV generator is oversized).
Restart limitation Following an external output limitation the inverter increases the
active power with dened progression (Pac progression and/or Soft
Start).
Frequency limitation The inverter temporarily limits the active power owing to an active
frequency-dependent power reduction.
External limitation The inverter's fed-in active power is limited by external output
control.
Temperature limitation The output power is temporarily reduced in order to limit the
inverter's temperature.
