7�8 Displaying the operating status of the MPP trackers
Via the "Status" menu it is possible to display the operating status of the MPP trackers
and the inverter. The displayed warnings and status messages are described in the Sec-
tions 7.7 and 8.2.
1. In the Main Menu, select the "Status" menu.
Figure 43 "Status" menu
Entry Description
System
Operating status of inverter (see also Section 7.7)
PU1
Operating status of MPP trackers 1 and 2 (Power unit 1)
PU2
Operating status of MPP trackers 3 and 4 (Power unit 1)
2. Press to return to the Main Menu.
