en
17
50
100
50
50
50 50
50
50
Figure 5 Minimum installation distances
Do not mount the inverter at an angle or on its side:
Figure 6 Unacceptable mounting positions
Appropriate cooling of the inverter can only take place when the ventilation openings
on the sides are kept clear.
The ambient air around the inverter must be free from dust, salt and ammonium
vapors.
The location must meet the requirements regarding emissions and freedom from
electromagnetic interference.
