20
Securing the inverter
7. Drill two Ø10 x 60 mm holes.
8. Secure the inverter with the 2 safety brackets (included in the delivery).
– Installation sequence: 10 x 50 wall plugs, safety bracket, M6 washers, 6 x 60 Torx
pan head screws.
Figure 10 Securing the inverter
Note
The safety brackets can also be tted laterally.
