Solartron 1260 - Group 3: Generator; Group 4: Learnt Program; History File; Vernier

27. GPIB/
PLOTTER
ERR.
If results are
to be
plotted from the
history
file, the
GPIB data output
should be set to
[off].
Or, if
results
are to
be
plotted
as
measurements are
made,
the
GPIB data output
should be set to
[plotter].
28.
NUL/NORMALIZE
ON You are not
allowed to
change
the sweep
parameters
when null or
normalize is selected.
29.
RENULL/NORMALIZE
Present
null/normalization data
invalid,
due
to
change in
sweep
parameter(s)
or
null/normalization
not yet done.
2.4
GROUP 3 :
GENERATOR
MESSAGE
EXPLANATION
31.
GENERATOR
KILLED
Generator output
killed. KILL
signal applied
to rear
panel
connector:
inner shorted to
outer, or
inner held
at
TTL logic 'O’.
32.
GENERATOR
O/LOAD
Generator overload,
or power
fail.
34. GEN
RESTART
Generator
output
reinstated.
KILL signal
removed
from rear
panel connector.
2.5
GROUP 4:
LEARNT
PROGRAM; HISTORY
FILE;
VERNIER
MESSAGE
40. FILE
CLEARED
41.
LINE NO.
ERROR
42. ILLEGAL
JUMP
EXPLANATION
History file
cleared.
Line
number
specified
in
a jump
instruction
(JPO
was
not
found.,
(Line numbers can be
assigned
only
in remotely
compiled programs).
Jump
has
been commanded
without
learn
program
selected.
43. OUT
OF RANGE
44. FILE
EMPTY
45.
ILL FILE
ACCESS
Vernier
adjustment
attempted
outside
parameter
range,
when
parameter is already at
maximum
value.’ (The
first attempt to
enter
a
value
outside the
parameter range,
with the
present setting
in range,
results
in the
parameter being set to
the
maximum
value: no
error message is
given at this time.)
History
file empty.
Illegal file access
attempted. It
is illegal to
display,
list, or clear the
history file whilst
the
analyzer is
running.
Or plot
attempted
whilst measurement
in progress.
(Plot uses
file contents.)
JWS/1260/2
9.5
