PLOTTER
Measurement
results
can be
plotted
on.
a suitable digital plotter.
The
PLOTTER
menu gives
a choice
of graphics
language,
plot
size
and
trace, and on/off
control
of
text and
grid and
axes.
5.1
[PLOTTER]
Trace,
text, grid, axes,
and graphics
language
selection.
5.1.1
MODE
Type of trace:
• [vector]
Adjacent
measurement
results
connected
by a straight line,
e.
g.
(S'
• [point]
Measurement
results plotted
as separate points,
e.g.
i
«S
lb.
5.1.2
TEXT
Plot
annotation:
•
ion]
X and Y
axes annotated
with
minimum
and maximum
values,
items,
units
(if appropriate),
title and
time.
• [off]
Results
plotted without
annotation.
5.1.3
GRID
Selects grid
on or off,
for
divisions along
the X
and Y axes.
5.18
