Sony BVW-55 User Manual

1-2
BVW-55
1-2. Matching Connectors/Cables
Connection made with the connector panels during installation or service, should be made with the
connectors or complete cable assemblies specified in the following list, or equivalent parts.
Panel indication Matching connector (Sony P/N) Matching cable (Sony P/N)
VIDEO REF IN Plug, BNC 75 Z (1-569-370-12) RG-59B/U cable
VIDEO INPUT
VIDEO OUTPUT
TC IN
TC OUT
SDI IN Plug, BNC 75 Z (1-569-370-12) BNC coaxial cable
SDI OUT (1-783-090-11:supplied with BKNW-225) or
BELDEN 8281 cable (Maximum cable length: 200m)
AUDIO INPUT XLR 3P, MALE (1-508-084-00) –––––––
AUDIO OUTPUT XLR 3P, FEMALE (1-508-083-00) –––––––
MONITOR OUTPUT
DC IN XLR 4P, FEMALE (1-508-362-00) DC power cord
(1-551-577-00:supplied with AC-550/550CE)
DC OUT Plug 4P MALE (1-566-425-11) –––––––
REMOTE Plug 9P MALE (1-560-651-00) 9P remote control cable
Shell, Junction 9P (1-561-749-00) (1-783-089-11:supplied with BKNW-225) or
RCC-5G(5 m)/10G(10 m)/30G(30 m)
AUX Plug 6P MALE (1-560-078-00) –––––––
HEADPHONES JM-60 stereo phone plug –––––––
(commercially available)
1-2. Matching Connectors/Cables

Sony BVW-55 Specifications

General

Type	Professional VCR
Video Format	Betacam SP
Video Standard	NTSC/PAL
Power Requirements	AC 100-240 V, 50/60 Hz
Video Heads	2
Frequency Response	20 Hz to 20 kHz
Signal-to-Noise Ratio	48 dB
Input/Output Connectors	Audio XLR
