4-16. JOG/SHUTTLE Dial Replacement
Outline
Replacement
JOG/SHUTTLE dial removal
JOG/SHUTTLE dial installation
Preparations
1. Turn off the power.
2. Remove the control panel. (Refer to Section 3-1-7.)
Tools
. Torque screwdriver (3 kg.cm): J-6325-400-A
. Torque screwdriver bit (for M1.4): J-6325-110-A
. Torque screwdriver bit (for M2): J-6325-380-A
4-16. JOG/SHUTTLE Dial Replacement
To Next Page
