1-3. Alignment Tape
Describes the alignment tapes using for adjusting the unit.
1. CR2-1B (SONY part No. 8-960-096-01) : For 525/60 system
Used for tracking adjustment.
Time (min. : sec.) Video Track AFM LTC track CTL track
00:00 -28:00 Y : 4 MHz — 7: 3 pulse CTL
C : 5 MHz
* The displayed TC data is interpolated by CTL signal due to the duty 7:3 pulse is recorded on the time code track.
2. CR5-1B (SONY part No. 8-960-096-41) : For 525/60 system
Used for video adjustment.
Time (min. : sec.) Video AFM LAU tracks CTL track
0:00 - RF sweep No signal No signal CTL
2:00 - 60% H sweep (CTDM) No signal No signal CTL
5:00 - Pulse & Bar (CTDM) No signal No signal CTL
8:00 - 60% multi-burst No signal No signal CTL
11:00 - Pulse & Bar No signal No signal CTL
14:00 - 75% color-bar 400 kHz sine wave No signal CTL
with 25 kHz deviation
16:30 - 75% color-bar 400 kHz sine wave No signal CTL
with 75 kHz deviation
17:00 - 50% bowtie & 12.5T No signal No signal CTL
19:00 - Line 17 No signal No signal CTL
22:00 - Quad phase No signal No signal CTL
24:00 - Flat filed No signal No signal CTL
26:00 - 75% color-bar with Drop-out No signal No signal CTL
28:00 - 30:00 Composite V sweep with VISC No signal No signal CTL
3. CR5-2A (SONY part No. 8-960-097-44) : For 525/60 system
Used for video adjustment.
Time (min. : sec.) Video LAU tracks CTL track
0:00 - 75% color-bar No signal CTL
3:00 - 60% multi-burst No signal CTL
6:00 - 50% bowtie & 12.5T No signal CTL
9:00 - Pulse & Bar No signal CTL
11:00 - Quad phase No signal CTL
13:00 - 15:00 Composite monoscope No signal CTL
(Switching position is shifted.)
1-3. Alignment Tape

Sony BVW-55 Specifications

General

Type	Professional VCR
Video Format	Betacam SP
Video Standard	NTSC/PAL
Power Requirements	AC 100-240 V, 50/60 Hz
Video Heads	2
Frequency Response	20 Hz to 20 kHz
Signal-to-Noise Ratio	48 dB
Input/Output Connectors	Audio XLR
