2-1
BVW-55
Section 2
Error Message
Ex. Superimposed on Video
Monitor and LCD monitor
2-1. Overview of Error Message
This unit has self-diagnostics function.
When trouble is detected, a WARNING indicator next the LCD monitor is lighted
immediately, and an error message is displayed on the sub LCD.
Also, an error code and error message are superimposed on the video monitor
connected to the VIDEO OUTPUT 2 (SUPER) connector and LCD monitor.
Furthermore, as for the some error codes, object which error occurred is displayed as
sub error message on the video monitor and LCD monitor.
m
. To superimpose the error message on the video monitor, set the SUPER item to
ON by using the general setting page of the sub LCD menu. (For sub LCD menu,
refer to the operation manual.)
. The error messages with error code are memorized to NV-RAM (Non-volatile
RAM) as the error logging data.
(Refer to Section 3 for the error logging data.)
. The messages on the sub LCD differ from the messages which are superimposed
on the LCD monitor (video monitor) in some items.
