2-2
BVW-55
Error messages are described on Section 2-2 in the order of list.
Error List
Code Message Page Description
on sub LCD display area
01 REEL TROUBLE 2-4 Tape slacking is detected in the unthreading operation.
02 REEL TROUBLE 2-5 Tape slacking or tape breaking is detected in the SEARCH, FF, or REW mode.
03 REEL TROUBLE 2-6 Tape slacking, or tape breaking is detected in the REC or PLAY mode.
04 REEL TROUBLE 2-7 A malfunctional tape transport speed is detected in the FF or REW mode.
06 TAPE TENSION 2-7 Excessive tape tension is detected in the REC or PLAY mode.
07 CAPSTAN TROUBLE 2-8 Abnormal capstan motor rotation speed is detected in the REC, PLAY, SEARCH, or REW
mode.
Malfunction of capstan FG is detected in the REC or PLAY mode.
08 DRUM TROUBLE 2-8 Malfunction of drum motor is detected.
09 FUNC. CAM MOTOR 2-9 Malfunction of threading or unthreading operation is detected.
10 HUMID 2-9 Dew condensation is detected.
12 TAPE TOP SENSOR 2-10 Malfunction of tape top sensor is detected.
13 TAPE END SENSOR 2-10 Malfunction of tape end sensor is detected.
14 FAN MOTOR 2-11 Malfunction of cooling fan motor is detected.
15 FULL TOP SENSOR 2-11 Malfunction of tape full top sensor is detected.
92 INTERNAL I/F 1 2-12 Abnormality in the interface between SYS CPU (on SY-272 board) and other CPU/MPU is
detected.
93 CPU INITIALIZE 2-12 Abnormality is detected in the communication between SERVO CPU (SV-206 board) and
DRUM MPU (SV-206 board).
96 SY NV-RAM ERROR 2-13 The abnormal operation of an NV-RAM (on SY-272 board) for the system control system is
detected.
97 SV NV-RAM 2-13 The abnormal operation of an NV-RAM (on SV-206 board) for the servo system is detected.
98 RF NV-RAM ERROR 2-14 The abnormal operation of an NV-RAM (on DM-121 board) for the RF system is detected.
99 INTERNAL I/F 2 2-14 Abnormality in the interface between SYS CPU (on SY-272 board) and SERVO CPU (on SV-
206 board) or MPU (on DM-121 or SDI-23 board) is detected.
m
. Error codes 01 through 13, and 15 are detected in the SV-206 board.
Error code 14 is detected in the SY-272 board.
Error codes 92 through 99 are detected in the SY-272 board.
. There are two error groups of error codes: VTR and OTHERS. If errors occur in multiple error groups, the error message
of each group are switched at two-second intervals.
Also, if multiple errors occur in error group, the priority level of each group display are as follows:
VTR: 97, 02, 03, 04, 07, 06, 01, 09, 08, 10, 12, 13, 14, 15
OTHERS: 92, 96, 98, 99, 93
