1-8
BVW-55 P2
1-2-2. Fixtures
Fig. Part No. Name For use Description
*
1 A-8321-000A Extension board (EX-706) Extension of plug-in boards P2
2 J-6035-070-A Extruction tool (for PLCC socket) Extruction of PLCC IC P2
3 J-6080-840-A Inspection mirror Tape curl check P2
4 J-6252-520-A Torque screwdriver Tightening screws of cabinet P1/P2
(12 kgf.cm) (1.2 N.m) [JB-5252] for installing and removing
J-6325-400-A Torque screwdriver (3 kgf.cm) Tightening screws (for M1.4 and M2 bit) P1/P2
5 J-6325-110-A Torque screwdriver bit (for M1.4) Tightening screws on mech. deck (l = 75 mm) P1/P2
6 J-6325-380-A Torque screwdriver bit (for M2) Tightening screws on drum, capstan, P1/P2
reel motor and boards (l = 162 mm)
7 J-6322-420-A Tape guide adjustment driver (45) Tape path adjustment P2
8 J-6323-530-A Stop washer fastening tool Installation of stop washer P2
9 J-6323-890-A Torque cassette (FWD BACK TEN.) [MW-389] FWD back tension REV back tension measurement P2
10 J-6324-150-A Reel table height adjustment tool [MW-415] Reel height check P2
11 J-6326-120-A Hexagon bit (for torque driver) Tightening screws on mechanical deck for P2
installing and removing (d = 1.5 mm, l = 85 mm)
12 J-6530-380-A Conversion cable, 6P - 9P Rewrite internal software P2
13 J-7032-610-B Cassette reference plate Reel height adjustment P2
14 3-184-527-01 Cleaning cloth (15 cm x 15 cm) Cleaning P1/P2
15 3-649-266-01 Parallel pin (d = 1.6 mm) Fixing position of cam gear P2
3-703-358-04 Parallel pin (d = 2.0 mm) Fixing position of threading gear/drawing arm P2
when installing
16 7-432-114-11 Screw locking compound (200g) Inhibits loosening of screws P2
17 7-651-000-10 Sony grease SGL-601 (50 g) P2
7-651-000-11 Sony grease SGL-801 (50 g) P1/P2
18 7-661-018-18 Diamond oil NT-68 (50 ml) P2
19 7-700-751-01 Nut driver (s = 4.5 mm) CTL/AT head height adjustment P2
20 8-960-096-01 Alignment tape, CR2-1B Tracking alignment P2
8-960-096-41 Alignment tape, CR5-1B (METAL) Video alignment P2
8-960-097-44 Alignment tape, CR5-2A (OXIDE) Betacam video alignment P2
8-960-097-45 Alignment tape, CR8-1A (OXIDE) Betacam audio alignment P2
21 9-919-573-01 Cleaning liquid Cleaning P1/ P2
22 A-8319-485-A IC memoy card box, CDS-20 assembly Software update P2
23 A-8322-417-A CN-1935 board Connection of the IC memory card box P2
24 1-772-003-11 IC memoy card (2 MB), MB98A81183 Software update P2
1-772-004-11 IC memoy card (4 MB), MB98A81273 Software update P2
25 1-958-196-14 Extension harness (SR66-EQ3) Extension of the RP-107 board P2
26 1-959-894-11 Extension harness (DR1) Extension of the RP-107 board P2
27 1-959-895-11 Extension harness (DR2) Extension of the RP-107 board P2
*: P1= Used in the maintenance manual Part 1./P2= Used in the maintenance manual Part 2.
Refer to “1-3. Alignment tape” for details of the alignment tapes.
1-2. Fixtures and Adjustment Equipment List
