Sony BVW-55 - T Idler Assembly Replacement

4-41
BVW-55 P2
4-12. T Idler Assembly Replacement
Outline
Replacement
Spring removal
Eject link assembly/release arm assembly removal
T idler assembly removal
T idler assembly installation
Eject link assembly/release arm assembly installation
Spring installation
Check after replacement
Operation check
Precaution
. The following new stop washer is required when replacing the T idler assembly.
Stop washer: 3-559-408-11 (4 pcs)
Preparations
1. Put the unit into the unthreading end state.
2. Turn off the power.
3. Remove the upper frame.
(Refer to the maintenance manual Part 1, Section 1-6.)
4. Remove the cassette compartment.
(Refer to the maintenance manual Part 1, Section 1-7.)
Tools
. Stop washer fastening tool: J-6323-530-A
. Torque screwdriver (3 kg.cm): J-6325-400-A
. Torque screwdriver bit (for M1.4): J-6325-110-A
. Oil: 7-661-018-18
. Cleaning cloth (15 cm x 15 cm): 3-184-527-01
. Cleaning liquid: 9-919-573-01
. Tweezers
4-12. T Idler Assembly Replacement
