1-37
BVW-55
1-12. Cleaning Clogged Video Heads
When the video heads are clogged, be sure to clean using a cleaning tape.
If the use of the cleaning tape does not solve clogged, clean using a cleaning cloth.
When using the cleaning tape, use the specified tape (or cloth) and follow only the instructions with an
extreme care.
If not, the video heads may be damaged or worn out.
For details on how to clean, refer to Section 4 “Periodic Maintenance and Inspection”.
Reference
To clean using a cleaning tape:
4-2-1. Using Cleaning Tape
To clean using a cleaning cloth:
4-2-2. General Information for the Use of Cleaning Cloth
4-2-3. Cleaning of Video Heads and Tape Running Surface of Upper Drum
Specified Cleaning Tape
BCT-5CLN
1-13. Power Protection
1-13-1. Overcurrent Protection
Overcurrent in the internal circuitry will trip the overcurrent protective device and will automatically
power down of the unit. If the device trips and the unit cannot be powered, turn off the power switch and
disconnect the cable connected at the DC IN connector and/or the battery, before checking the circuit for
overcurrent.
After the check, turn on the power switch. The unit will be powered if the cause of overcurrent is cleared.
1-13-2. Information on IC Link
The unit is equipped with two IC links. One is F1 on the FL-251 board, and the other is PS600 on the CP-
317 board. F1 on the FL-251 board will blow when the overcurrent flows because of internal circuit
failure. PS600 on the CP-317 board will blow by overcurrent when an equipment connected at the DC
OUT connector fails. If some IC link blows, turn off the power switch and disconnect the cable connect-
ed at the DC IN connector and/or the battery, before checking the circuit for overcurrent.
When replacing, be sure to use the specified part.
w
The IC links are critical for safe operation. Be sure to use the specified part to avoid the danger of a fire
or electric shock.
Board Ref.No. Description Part No.
FL-251 F1 IC LINK 0.4 A ! 1-576-122-21
CP-317 PS600 IC LINK 2 A ! 1-533-282-21
