1-41
BVW-55
1-15-2. Equipment for Adjustment
It is recommended to use the equipment listed below or the equivalents.
Each equipment is available as a standard product.
Equipment Model name Remarks Description
*1
Serial digital component video Tektronix TSG-422-OP.1S for generating 4:2:2 format digital signal P2
signal generator
Analog composite video signal generator Tektronix TSG-170A for 525/60 system P2
Serial digital component monitor Tektronix WFM601 P2
Analog composite waveform / vector monitor Tektronix 1750 or 1780R for measuring analog composite signal P2
for 525/60 system
Tektronix 1751 or 1781R for measuring analog composite signal
for 625/50 system
Oscilloscope Tektronix 2465B P2
Analog component waveform monitor Tektronix WFM300 for video phase adjustment P2
Spectrum analyzer Advantest R3261A with external trigger function P2
bandwidth: more than 100 MHz
Network analyzer Anritsu MS420B P2
Audio signal generator Tektronix SG505-OP.02 P2
Audio analyzer Tektronix AA501A-OP.02 for measuring distortion and levels P2
Audio level meter Hewlett-Packard HP3400A P2
Digital voltmeter Advantest TR6845 P2
Composite video monitor Sony BVM-14F5U or P2
BVM-14F5E
*2
OP. BKM-24N for 525/60 system
OP. BKM-25P for 625/50 system
Terminator 75 Z BNC type P2
Recording tape Sony Betacam SP tape (BCT-30MA, etc.) P2
Sony Betacam tape (BCT-20G, etc.) P2
*1: P2= Used in the maintenance manual Part 2.
*2: Use the composite video monitor that is applicable to the places in the world
1-15. Fixtures and Adjustment Equipment List

Sony BVW-55 Specifications

General

Type	Professional VCR
Video Format	Betacam SP
Video Standard	NTSC/PAL
Power Requirements	AC 100-240 V, 50/60 Hz
Video Heads	2
Frequency Response	20 Hz to 20 kHz
Signal-to-Noise Ratio	48 dB
Input/Output Connectors	Audio XLR
