BVW-55
VTR CONSTANT 1 VTR CONSTANT 2
Data No. Data No.
System 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
525/60 System
20 60 00 96 05 05 04 8B 0A 08 FB 00 8D 3D FF 4C
625/50 System 21 60 00 7D 05 05 04 8B 0A 07 FB 00 8F 4B FF 4C
Values are represented in hexadecimal
1-16. Settings for External Editors
1-16-1. Time Code Settings for Recorder
When editing with an editor capable of the 1st-edit (BVE-2000)
. Time code operation block on the control panel
INT/EXT switch 8 INT
PRESET/REGEN switch 8 PRESET
F-RUN/R-RUN switch 8 F-RUN
When editing directly from VTR to VTR
n
Make sure that the setting of ITEM-610 on the setup menu is as follows:
. ITEM-610: REGEN CONTROL MODE 8 AS & IN
. Time code operation block on the control panel
INT/EXT switch 8 INT
PRESET/REGEN switch 8 PRESET
F-RUN/R-RUN switch 8 R-RUN
1-16-2. VTR Constant Settings for External Editors
The following constants are standard for each type and system listed.
When using an external editor which requires the VTR constants, use the settings listed. VTR constants
must also be set when switching between the 525 and 625 line systems.
m
1. Set the data No. 8 of VTR CONSTANT 1 to 0A for the following editors.
. BVE-900 ROM version 1.08 or lower
. BVE-600 ROM version 1.01 or lower
2. If the unit is controlled by the editor, be sure to set ITEM-401 on the setup menu as follows:
. ITEM-401: FUNCTION MODE AFTER CUE-UP 8 STOP
1-16. Settings for External Editors
