1-33
BVW-55
SDI-23 Board
n
The indicators D302 to D305 function properly when the received signal conforms to the EDH
*
(with
D301 lit).
* EDH : Error Detection and Handling
Ref.No. Indicator name Color Description Normal state
D300 SDI INPUT EXIT Green Lit when detecting the SDI format signal input On
at SDI IN connector
D301 RX EDH VALIDITY Green Lit when the received signal at SDI IN connector On
conforms to the EDH
D302 RX EDH OTHER Red Lit when another ancillary data exists in the EDH portion Off
ANC ERROR of the received signal at SDI IN connector
D303 RX EDH ACTIVE Red Lit when an active picture EDH error is detected from the Off
PICTURE ERROR received signal at SDI IN connector
D304 RX EDH FULL Red Lit when a full-field EDH error is detected from the Off
FIELD ERROR received signal at SDI IN connector
D305 RX EDH ANCILLARY Red Lit when an ancillary data EDH error is detected from Off
DATA ERROR the received signal at SDI IN connector
D800 SDI TRS NO ERROR Green Lit when the SDI format signal is normally received On
at SDI IN connector
D801 VCO ADJ OF Green Lit when EVR (electronic volume) data comes near its –––
MAINTENANCE proper value during VCO free-run adjustment in the
maintenance mode
SY-272 Board
Ref.No. Indicator name Color Description Normal state
D202 SY STS1 Green Blinks when the SYS CPU normally operates Blinking
D205 SY ERR Red Lit when the SYS CPU does not normally operate Off
Blinks when communication between SYS CPU and
other CPU/ MPU (SV CPU or KY MPU) is under
abnormal conditions
1-10. Description on Internal Indicators
