Chapter 6 Setup Menu
118
Chapter 6 Setup Menu
Extended Menu
Item number Item name Settings
501 STILL TIMER Select the time delay from the tape transport stopping (either the "STOP" mode" or the
still playback mode in search mode) until the unit automatically switches to the tape
protection mode, in order to protect the rotary heads and the tape.
0.5S... 1M ..5M: Set the value in the range 0.5 seconds to 5 minutes.
Menu items in the 500s, relating to tape protection
502 TAPE
PROTECTION
MODE FROM
SEARCH
Select the operation of the protection mode to protect the rotary heads and tape when in
the still playback mode in search (jog/shuttle) mode.
STEP : Step forward at
1
/
30
normal speed at the time interval set with STILL TIMER.
STDBY: Switch to Standby OFF mode (the unit not on standby).
Item number Item name Settings
Menu items in the 600s, relating to the time code generator
601
VITC POSITION
SEL-1
For DSR-2000
Select a line to insert the VITC in.
12H ... 16H ... 20H: Select any line from 12 to 20.
Note
You can insert the VITC signal in two places. To insert it in two places, set both items
601 and 602.
For DSR-2000P
Select a line to insert the VITC in.
9H ... 19H ... 22H: Select any line from 9 to 22.
Note
You can insert the VITC signal in two places. To insert it in two places, set both items
601 and 602.
602 VITC POSITION
SEL-2
For DSR-2000
Select a line to insert the VITC in.
12H ... 18H ... 20H: Select any line from 12 to 20.
Note
You can insert the VITC signal in two places. To insert it in two places, set both items
601 and 602.
For DSR-2000P
Select a line to insert the VITC in.
9H ... 21H ... 22H: Select any line from 9 to 22.
Note
You can insert the VITC signal in two places. To insert it in two places, set both items
601 and 602.
Chapter 6 Setup Menu
Chapter 6 Setup Menu
119
Item number Item name Settings
605 TCG REGEN
MODE
Select the signal to be regenerated when the time code generator is in the regeneration
mode (i.e., when the PRESET/REGEN switch on the subsidiary control panel is set to
REGEN, or the unit is in automatic edit mode).
TC&UB : Both the time code and user bits are regenerated.
TC: Only the time code is regenerated.
UB: Only the user bits are regenerated.
Menu items in the 600s, relating to the time code generator
607 U-BIT BINARY
GROUP FLAG
610 REGEN
CONTROL MODE
When editing with two DSR-2000/2000P units, if you use the control panel for editing
operation, select whether or not the time code is automatically regenerated.
AS&IN : In editing with this unit as the recorder, regardless of the setting of the INT/
EXT–PRESET/REGEN switch, in assemble and insert editing, the time code
generator regenerates according to the time code on the tape.
ASSEM: In editing with this unit as the recorder, regardless of the setting of the INT/
EXT–PRESET/REGEN switch, in assemble editing only, the time code generator
regenerates according to the time code on the tape.
MANU: Regardless of whether this unit is the recorder or player, the time code
generator operates in accordance with the PRESET/REGEN setting of the INT/EXT
–
PRESET/REGEN switch.
FULL: Regardless of the REMOTE button setting, when any of the ASSEMBLE,
VIDEO, CH-1 to CH-4 and TC buttons is lit, the time code generator regenerates
according to the time code played back from the tape.
611 TC OUTPUT
PHASE IN EE
MODE
Select the time code output mode for output from the TIME CODE OUT connector in E-
E mode.
MUTE : Mute the output.
THRU: Output the time code input to the TIME CODE IN connector as it is.
V-IN: Output the time code with the same phase as the input video signal phase.
V-OUT: Output the time code with the same phase as the output video signal phase.
612 TC OUTPUT
MUTE IN
SEARCH MODE
Select whether to mute the output from the TIME CODE OUT connector in search (jog/
shuttle) mode.
ON : Mute.
OFF: Do not mute.
Select the user bits to be used in the time code generated by the time code generator.
000 : Character set not specified.
001: 8-bit characters compliant with ISO 646 and ISO 2022.
010: Undefined.
011: Undefined.
100: Undefined.
101: SMPTE 262M page/line multiplex system.
110: Undefined.
111: Undefined.
613 VITC OUTPUT Select the time code to be output as VITC.
OFF: Do not output VITC.
TC: Output TC after converting it into VITC.
VITC : Output VITC.
