1-1. DSR-2000
Chapter 6 Setup Menu
120
Chapter 6 Setup Menu
Extended Menu
Item number Item name Settings
Menu items in the 700s, relating to video control
Item number Item name Settings
715 VIDEO GAIN
CONTROL
Adjust the video output level.
00H to 200H to 3FFH
Items 715 to 720 : Settings for controlling the video processing system according to the menu settings.
716 CHROMA GAIN
CONTROL
Adjust the chroma output level.
00H to 200H to 3FFH
717 CHROMA PHASE
CONTROL
Adjust the chroma phase.
00H to 80H to FFH
718
SETUP LEVEL
(DSR-2000)/
BLACK LEVEL
(DSR-2000P)
Adjust the setup level (DSR-2000)/black level (DSR-2000P).
00H to 200H to 3FFH
701
SELECTION OF
VIDEO/SYNC
DELAY
An E-E video signal is output delayed with respect to the video input signal by the time for
video circuit processing. With this item, select whether or not to delay the sync signal
attached to the output video signal by an amount corresponding to the video signal delay.
SYNC : Delay the sync signal by the corresponding amount before attaching it.
VIDEO: Attach a sync signal with the same timing as the input signal.
720
SYSTEM PHASE
SC
Adjust the subcarrier phase.
00H to 3FFH
705
EDGE
SUBCARRIER
REDUCER MODE
Select whether to enable the edge subcarrier reducer (ESR).
ON : Enable.
OFF : Do not enable.
When playing back a composite signal, set this to ON.
708 CHROMA PHASE
ROTATION MODE
Select the phase rotation mode for chroma phase control.
The effect of this setting applies to the output levels of all of the composite video, S
video, SDI and component video signals.
U/V : Select this setting when observing the unit's composite video output level using a
composite vectorscope.
PB/PR: Select this setting when observing the unit's component video output level using
a component vectorscope.
713 VIDEO SETUP
REFERENCE
(DSR-2000 only)
Select whether to remove the setup (7.5%) from the input analog video signals and
whether to add the setup (7.5%) to the output analog video signals.
714 VIDEO ADJUST
RANGE
Select the variable range of the VIDEO and CHROMA knobs when the PROCESS
CONTROL switch on the subsidiary control panel is set to PANEL.
–3~+3 : –3 dB to +3 dB
WIDE: – ∞ to +3 dB
Sub-item
INPUT LEVEL1
2
OUT PUT LEVEL
Whether to remove the setup from the input.
0.0% : Do not remove.
7.5%: Remove.
Whether to add the setup to the output.
0.0% : Do not add.
7.5%: Add.
710
INTERNAL VIDEO
SIGNAL
GENERATOR
Select the test signal to be output from the internal test signal generator.
CB100 (DSR-2000P only): 100% color bar signal
CB75: 75% color bar signal
BB: Black burst signal
Default setting: CB100 (for DSR-2000P)/CB75 (for DSR-2000)
Chapter 6 Setup Menu
Chapter 6 Setup Menu
121
Item number Item name Settings
Menu items in the 700s, relating to video control (continued)
729 CLOSED
CAPTION BLANK
(DSR-2000 only)
Select whether to mute the closed caption signal to be superimposed on the 1st and
2nd fields of the output video signal.
Sub-item
FIELD 1
1
2 FIELD 2
Select whether to mute the closed caption signal to be superimposed on the 1st field of
the output video signal.
OFF : Do not mute.
ON: Mute.
Select whether to mute the closed caption signal to be superimposed on the 2nd field of
the output video signal.
OFF : Do not mute.
ON: Mute.
Note
When you make settings for items 715 to 720, set the
PROCESS CONTROL switch on the subsidiary
control panel to MENU. When it is set to MENU, all
controls on the subsidiary control panel are disabled.
Item number Item name Settings
801 DIGITAL JOG
SOUND
Select whether to adjust the audio playback speed during slow playback.
OFF: Do not adjust the audio playback speed.
ON : Adjust the audio playback speed.
Menu items in the 800s, relating to audio control
802 DIGITAL AUDIO
MUTE IN
SHUTTLE MODE
Set the audio muting conditions during shuttle playback.
OFF : Not muted.
CUEUP: Muted during cue-up or preroll operations.
FULL: Muted in shuttle mode.
807 AUDIO OUTPUT
PHASE
Select the output timing of an audio playback signal. The reference position corresponds
to a setting of 80H; when the setting is less than 80H, the output timing is advanced,
and when it is higher than 80H, the output timing is delayed. (80H = 128 samples =
approx. 2.7 ms, 1 sample = approx. 20 µs)
0 ... 80 ... FF : Setting in this range.
(Continued)
723 INPUT VIDEO
BLANK
(DSR-2000P only)
Switching blanking on or off for the 335th line of the input video signal. Select the
reference video signal to use.
Sub-item
LINE335
THROUGH : Do not mute.
BLANK: Mute.
731 WIDE MODE Determine whether to retain wide-screen aspect ratio information accompanying video
being recorded or played back.
AUTO : When video being recorded or played back is accompanied by wide-screen
aspect ratio information, retain the information.
ON: Whenever recording or playing back video, retain wide-screen aspect ratio
information.
OFF: Ignore wide-screen aspect ration information.
To Next Page
