Sony HDS-7150 - Set-Up; Confirmation of the Software Version; Setting about the System; Setting the Date and Time

10-8
HDS-7150/7100
F1 F2 F3 F4 F5 F6
SETUP SYSTEM INPUT OUTPUT EFFECT PERIPH
10-3. Set-up
The processes to construct the system are described below.
Basically perform the set-ups in the following sequence.
However, it is not necessary to re-set the item whose setting is not changed.
1. Confirmation of the Software Version
2. Setting about the System
3. Setting the Date and Time
4. Assigning of the Crosspoint
5. Assigning of the Key Source to the Key Fill (When the key source auto select mode is selected)
6. Adjusting the Input Signal
7. Adjusting the Outputs of the Entire System
8. Adjusting the Output Signal
9. Setting about the Change of Synchronization Signal Assignment
10. Setting of the Internal Generation Matte Signal
11. Setting of the Desired DME
12. Setting of the DME Interface
13. Setting of the GPI Input
14. Setting of the GPI Output
Discontinuing the Setting
To save the data to nonvolatile memory when discontinuing or terminating the set-up, refer to “10-4.
Saving Set-up Data to Nonvolatile Memory.”
Adjustment and Set Values
For details of adjustment and set values of each item, refer to the User’s Guide.
Set-up Menu Operation (Initial Set-up Screen)
After turning on the main power and pressing the SETUP button, the initial set-up screen appears and the
above items 1 to 14 can be selected.
If the set-up menu screen is already displayed, the SETUP button does not need to be pressed.
HDS-7100
10-3. Set-up
