2-7. Description of Switches and LEDs on Boards
2-7. Description of Switches and LEDs on Boards
n
The address on the board is shown in the parentheses.
2-7-1. Power Indicators on CKG-26/CPU-183/CRK-9/DI-37/DLP-17/DSK-16/MEM-
65C/MEM-65K/MEM-65Y/MIX-43/MPU-111/OUT-20/VSE-19/VSE-20/VSE-21/
VSW-66/WKG-29 Boards
The following boards (including the optional boards) have the LEDs indicating status of +5 V, +3 V,
+12 V, _5 V and other power supplies. Reference numbers of the LEDs and addresses on the respective
boards are shown below.
The boards are listed in the order of slots.
Power voltage/Display LED +5 V +3 V _5 V +12 V _2 V
Board Name VCC VDD VEE
CPU-183 D6 (Q-5) D7 (Q-5) D5 (Q-5)
CKG-26 D13 (Q-2) D14 (Q-4) D15 (Q-3)
VSE-19 (HKDS-7061) D1 (Q-11) D6 (Q-11)
DLP-17 (HKDS-7061) D3 (Q-11) D4 (Q-11)
CPU-183 (HKDS-7071) D6 (Q-5) D7 (Q-5) D5 (Q-5)
MPU-111 (HKDS-7071) D1 (Q-2) D2 (Q-3)
MEM-65Y (HKDS-7071) D3 (R-11) D4 (R-11)
MEM-65C (HKDS-7071) D3 (R-11) D4 (R-11)
MEM-65K (HKDS-7071) D3 (R-11) D4 (R-11)
VSE-20 (HKDS-7071) D3 (Q-11) D4 (Q-11)
VSE-21 (HKDS-7071) D3 (Q-11) D4 (Q-11)
CRK-9 (HKDS-7031) D2 (Q-11) D4 (Q-11)
MIX-43 D2 (R-11) D3 (R-11)
WKG-29 D1 (F-11) D2 (F-11)
VSW-66 D39 (R-11) D40 (R-11)
DSK-16 D1 (D-2) D2 (D-1)
DI-37 D1 (Q-11) D2 (Q-11) D3 (Q-11) D4 (Q-11),
D35 (Q-11)
OUT-20 D7 (Q-11) D8 (Q-11) D9 (Q-11) D10 (Q-11)
