6-2
HDS-7150/7100
BKDM-3010
6-3. Matching Connectors
6-3. Matching Connectors
When connecting cables to various connectors on the rear panel at the time of installing, connecting or
servicing, connect the following connectors or their equivalents.
Connector indication on rear panel Connector parts No. and name (cable side)
PROCESSOR D-sub 25-pin, Male
Connector 25-pin, Male : 1-560-904-11
Junction Shell 25-pin : 1-563-377-11
MONITOR Supplied with a CPD-15SF8
SPARE A PCY-330 or a Microsoft mouse
To Next Page
