5-5
HDS-7150/7100
5-4. Matching Connectors
When connecting cables to various connectors on the rear panel at the time of installing, connecting or
servicing, connect the following connectors or their equivalents.
Connector indication on rear panel Connector parts No. and name (cable side)
SWITCHER D-sub 9-pin, Male
TERMINAL
Connector 9-pin, Male : 1-560-651-00
*1
SPARE
Junction Shell 9-pin : 1-561-749-00
AC IN Power Supply Cord
(For the details of the power cord, refer to Section 1-2-3.)
*1 : The following solderless contact must be used for the plug.
AWG #18 to #22 : 1-566-493-21
AWG #22 to #24 : 1-564-774-11
AWG #24 to #30 : 1-564-775-11
BKDS-2010
5-4. Matching Connectors
