Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAP-S1
111111
R1045 1-218-990-81 SHORT CHIP 0
R1046 1-218-990-81 SHORT CHIP 0
R1047 1-218-941-81 METAL CHIP 100 5% 1/16W
R1050 1-216-296-11 SHORT CHIP 0
R1051 1-216-296-11 SHORT CHIP 0
R1052 1-218-990-81 SHORT CHIP 0 (CND)
R1053 1-218-990-81 SHORT CHIP 0 (CND)
R1054 1-218-990-81 SHORT CHIP 0 (CND)
R1055 1-218-954-11 METAL CHIP 1.2K 5% 1/16W
R1056 1-218-950-11 METAL CHIP 560 5% 1/16W
R1057 1-216-864-11 SHORT CHIP 0
R1058 1-216-864-11 SHORT CHIP 0
R1059 1-218-990-81 SHORT CHIP 0
R1060 1-216-864-11 SHORT CHIP 0
R1061 1-216-864-11 SHORT CHIP 0
R1062 1-216-864-11 SHORT CHIP 0
< COMPOSITION CIRCUIT BLOCK >
RB501 1-234-371-11 RES, NETWORK 47 (1005X4)
RB502 1-234-371-11 RES, NETWORK 47 (1005X4)
RB503 1-234-371-11 RES, NETWORK 47 (1005X4)
RB504 1-234-371-11 RES, NETWORK 47 (1005X4)
RB505 1-234-371-11 RES, NETWORK 47 (1005X4)
RB506 1-234-371-11 RES, NETWORK 47 (1005X4)
RB507 1-234-371-11 RES, NETWORK 47 (1005X4)
RB508 1-234-371-11 RES, NETWORK 47 (1005X4)
RB509 1-234-371-11 RES, NETWORK 47 (1005X4)
< THERMISTOR >
TH001 1-805-194-21 THERMISTOR, NTC (SMD)
< VIBRATOR >
X200 1-814-485-11 QUARTZ CRYSTAL UNIT (48 MHz)
X201 1-814-466-11 QUARTZ CRYSTAL UNITS (12.288 MHz)
X202 1-814-767-11 QUARTZ CRYSTAL UNITS (13.333 MHz)
X203 1-814-273-11 QUARTZ CRYSTAL UNIT (32.768 kHz)
X501 1-814-023-11 QUARTS CRYSTAL UNIT (27 MHz)
X901 1-795-779-21 VIBRATOR, CRYSTAL (22.5792 MHz)
X902 1-814-344-11 QUARTZ CRYSTAL UNIT (24.576 MHz)
*************************************************************
MS-091 BOARD
************
When the MS-091 board is defective, replace the LOADING ASSY (Ref. No.
CDM1).
*************************************************************
A-2054-090-A NETWORK BOARD, COMPLETE
(AEP, UK, AUS, HK, MY)
A-2057-120-A NETWORK BOARD, COMPLETE (CND)
*************************
< CAPACITOR >
C3003 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C3005 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C3008 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C3011 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C3012 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C3013 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C3014 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C3015 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C3016 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C3017 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C3018 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C3019 1-118-388-11 CERAMIC CHIP 0.047uF 10% 25V
C3020 1-118-388-11 CERAMIC CHIP 0.047uF 10% 25V
* C3021 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
C3022 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3024 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C3025 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3026 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C3027 1-116-708-11 CERAMIC CHIP 47uF 20% 6.3V
C3045 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN3001 (Not supplied) CONNECTOR, BOARD TO BOARD 120P
(See Note 1)
CN3002 1-815-194-11 CONNECTOR, USB (B) (
)
CN3005 1-770-160-21 PIN, CONNECTOR (PC BOARD) 2P
CN3009 1-770-161-21 PIN, CONNECTOR (PC BOARD) 6P
CN3010 1-784-879-51 CONNECTOR, FFC (LIF (NON-ZIF)) 31P
< FERRITE BEAD >
FB3001 1-400-198-21 INDUCTOR, FERRITE BEAD (1005)
FB3004 1-400-198-21 INDUCTOR, FERRITE BEAD (1005)
< IC >
IC3001 (Not supplied) IC FSUSB63UMX (See Note 1)
IC3002 6-719-012-01 IC S-13A1A12-E6T1U3
< CONNECTOR >
J3001 1-843-693-11 ETHERNET CONNECTOR (LAN)
< JUMPER RESISTOR >
JC3001 1-216-864-11 SHORT CHIP 0
JC3002 1-216-864-11 SHORT CHIP 0
JC3004 1-216-864-11 SHORT CHIP 0
JC3006 1-216-864-11 SHORT CHIP 0
JC3007 1-216-295-91 SHORT CHIP 0
JC3008 1-216-295-91 SHORT CHIP 0
JC3009 1-216-295-91 SHORT CHIP 0
JC3012 1-216-864-11 SHORT CHIP 0
JC3013 1-216-864-11 SHORT CHIP 0
JC3015 1-216-864-11 SHORT CHIP 0
(Suffi x-11/Suffi x-12: CND) (See Note 2)
JC3017 1-216-864-11 SHORT CHIP 0
JC3018 1-216-864-11 SHORT CHIP 0
JC3019 1-216-864-11 SHORT CHIP 0
JC3021 1-216-864-11 SHORT CHIP 0
JC3022 1-216-864-11 SHORT CHIP 0
JC3023 1-216-864-11 SHORT CHIP 0
JC3024 1-216-864-11 SHORT CHIP 0
(Suffi x-12: AEP, UK, AUS, HK, MY)
< COIL >
L3001 1-457-223-11 COMMON MODE CHOKE COIL
L3002 1-457-223-11 COMMON MODE CHOKE COIL
< RESISTOR >
R3001 1-218-937-11 METAL CHIP 47 5% 1/16W
R3002 1-218-937-11 METAL CHIP 47 5% 1/16W
Note 2: Refer to the “NEW/FORMER DISCRIMINATION OF MAIN, NET-
WORK, FRONT-L AND AMP BOARDS” on page 4 for how to distin-
guish suffi x-11 and suffi x-12 of NETWORK board for Canadian model.
Note 1: CN3001 and IC3001 on the NETWORK board cannot
replace with single. When these parts are damaged, re-
place the complete mounted board.
