Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAP-S1
112
R3003 1-218-937-11 METAL CHIP 47 5% 1/16W
R3004 1-218-945-11 METAL CHIP 220 5% 1/16W
(CND)
R3004 1-400-823-11 EMI FERRITE (SMD) (1005)
(AEP, UK, AUS, HK, MY)
R3005 1-218-937-11 METAL CHIP 47 5% 1/16W
R3008 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3009 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3010 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3011 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3012 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3013 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3016 1-218-937-11 METAL CHIP 47 5% 1/16W
R3017 1-218-937-11 METAL CHIP 47 5% 1/16W
R3018 1-218-937-11 METAL CHIP 47 5% 1/16W
R3019 1-218-937-11 METAL CHIP 47 5% 1/16W
R3020 1-218-937-11 METAL CHIP 47 5% 1/16W
R3021 1-218-937-11 METAL CHIP 47 5% 1/16W
R3022 1-218-937-11 METAL CHIP 47 5% 1/16W
R3023 1-218-937-11 METAL CHIP 47 5% 1/16W
R3024 1-218-937-11 METAL CHIP 47 5% 1/16W
R3025 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3027 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3031 1-218-990-81 SHORT CHIP 0
R3032 1-218-929-11 METAL CHIP 10 5% 1/16W
R3033 1-218-929-11 METAL CHIP 10 5% 1/16W
R3034 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3035 1-218-969-11 METAL CHIP 22K 5% 1/16W
R3041 1-218-990-81 SHORT CHIP 0
R3050 1-218-990-81 SHORT CHIP 0
R3051 1-218-990-81 SHORT CHIP 0
R3052 1-218-990-81 SHORT CHIP 0
R3053 1-218-990-81 SHORT CHIP 0
R3059 1-218-990-81 SHORT CHIP 0
R3060 1-218-990-81 SHORT CHIP 0
R3061 1-218-990-81 SHORT CHIP 0
R3062 1-218-990-81 SHORT CHIP 0
R3063 1-218-990-81 SHORT CHIP 0
R3064 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3065 1-218-973-11 METAL CHIP 47K 5% 1/16W
*************************************************************
A-1990-311-A SUBPOWER BOARD, COMPLETE (CND)
A-1990-329-A SUBPOWER BOARD, COMPLETE
(AEP, UK, AUS, HK, MY)
**************************
< CAPACITOR >
C5001 1-136-165-00 FILM 0.1uF 5% 50V
C5002 1-136-165-00 FILM 0.1uF 5% 50V
C5003 1-126-944-11 ELECT 3300uF 20% 25V
C5004 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
0 C5005 1-113-924-51 CERAMIC 0.0047uF 20% 250V
C5006 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C5007 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C5008 1-126-944-11 ELECT 3300uF 20% 25V
C5009 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C5010 1-136-165-00 FILM 0.1uF 5% 50V
C5011 1-136-165-00 FILM 0.1uF 5% 50V
< CONNECTOR >
CN5001 1-564-507-11 PLUG, CONNECTOR 4P
0 * CN5002 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
0 * CN5003 1-565-792-11 PIN, CONNECTOR (3.96 mm PITCH) 2P
< DIODE >
D5001 8-719-085-36 DIODE 11EQS04-TB5
D5002 8-719-085-36 DIODE 11EQS04-TB5
D5003 8-719-085-36 DIODE 11EQS04-TB5
D5004 8-719-085-36 DIODE 11EQS04-TB5
D5005 6-502-961-01 DIODE DA2J10100L
D5006 6-500-522-31 DIODE 10EDB40-TB5
D5007 6-500-522-31 DIODE 10EDB40-TB5
D5008 6-500-522-31 DIODE 10EDB40-TB5
D5009 6-500-522-31 DIODE 10EDB40-TB5
< FUSE >
0 F5001 1-532-504-33 FUSE (T 4 AL/250 V)
0 F5002 1-532-504-33 FUSE (T 4 AL/250 V)
< FUSE HOLDER >
FH5001 1-533-217-31 FUSE HOLDER
FH5002 1-533-217-31 FUSE HOLDER
FH5003 1-533-217-31 FUSE HOLDER
FH5004 1-533-217-31 FUSE HOLDER
< TRANSISTOR >
Q5001 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R5001 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R5002 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< RELAY >
0 RY5001 1-755-703-11 RELAY
< TRANSFORMER >
0 T5001 1-445-048-21 TRANSFORMER, LINE FILTER
0 T5002 1-697-347-11 SUB TRANS (CND)
0 T5002 1-697-349-11 SUB TRANS (AEP, UK, AUS, HK, MY)
*************************************************************
A-1990-335-A TUNER BOARD, COMPLETE
(AEP, UK, AUS, HK, MY)
A-2035-808-A TUNER BOARD, COMPLETE (CND)
**********************
When the TUNER board is defective, replace the complete mounted board.
*************************************************************
A-1990-321-A USB BOARD, COMPLETE
********************
< CAPACITOR >
C4001 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C4005 1-116-708-11 CERAMIC CHIP 47uF 20% 6.3V
< CONNECTOR >
CN4001 1-793-365-21 CONNECTOR, USB (A) (
5V 2.1A)
CN4004 1-822-067-51 CONNECTOR, FFC/FPC 5P
CN4005 1-774-297-21 PIN, CONNECTOR (PC BOARD) 7P
NETWORK SUBPOWER TUNER USB
