< IC >
IC4001 6-717-427-01 IC TPS2561DRCR
< RESISTOR >
R4002 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R4003 1-208-895-81 METAL CHIP 2.2K 0.5% 1/16W
R4004 1-218-990-81 SHORT CHIP 0
R4005 1-218-990-81 SHORT CHIP 0
R4007 1-218-990-81 SHORT CHIP 0
R4008 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4009 1-218-973-11 METAL CHIP 47K 5% 1/16W
R4010 1-216-295-91 SHORT CHIP 0
R4011 1-216-295-91 SHORT CHIP 0
R4012 1-216-295-91 SHORT CHIP 0
*************************************************************
MISCELLANEOUS
**************
0 AC1 1-843-976-11 AC INLET (2P) (
-
AC IN) (CND)
0 AC1 1-843-976-21 AC INLET (2P) (
-
AC IN) (AEP, UK, AUS, HK, MY)
ANT1 1-754-859-11 ANTENNA (2.4 GHz) (WiFi antenna) (See Note 1)
BT1 1-490-558-81 BLUETOOTH MODULE
CC1 1-820-441-11 CONNECTOR, COAXIAL (F TYPE)
(AEP, UK, AUS, HK, MY)
CDM1 A-1990-245-A LOADING ASSY
(Including MS-091 board, loading motor)
DAB1 1-489-807-11 MODULE (DAB TUNER) (AEP, UK, AUS, HK, MY)
* FC1 1-500-082-11 CLAMP, SLEEVE FERRITE
(AEP, UK, AUS, HK, MY)
FC2 1-481-530-21 FILTER, CLAMP (FERRITE CORE)
FC3 1-500-635-11 CORE, FERRITE
FC4 1-481-529-21 FILTER, CLAMP (FERRITE CORE) (CND)
FC5 1-481-530-21 FILTER, CLAMP (FERRITE CORE)
* FC6 1-500-082-11 CLAMP, SLEEVE FERRITE
FFC1 9-885-194-29 FY14 FFC (1.0 mm_23P_JOINT)
FFC2 9-885-194-19 FY14 FFC (0.5 mm_26P_JOINT)
FFC3 9-885-194-24 FY14 FFC (1.0 mm_5P_USB)
FFC4 9-885-194-22 FY14 FFC (1.0 mm_9P_VOL)
FFC5 9-885-194-28 FY14 FFC (1.0 mm_19P_FL)
FFC6 9-885-194-17 FY14 FFC (0.5 mm_8P_NFC)
FFC7 9-885-194-20 FY14 FFC (0.5 mm_14P_BT)
FFC8 9-885-194-25 FY14 FFC (1.0 mm_7P_CDM)
FFC9 9-885-194-18 FY14 FFC (0.5 mm_24P_OP)
FFC10 9-885-194-26 FY14 FFC (1.0 mm_9P_AMP)
FFC11 9-885-194-21 FY14 FFC (1.0 mm_9P_TUNER)
FFC12 9-885-194-23 FY14 FFC (1.0 mm_9P_DAB)
(AEP, UK, AUS, HK, MY)
FFC13 9-885-194-27 FY14 FFC (1.0 mm_31P_NET)
0 M1 1-855-247-11 FAN, DC
NFC1 8-989-470-05 RC-S801 (NFC module)
0 OP1 A-1940-584-A OPTICAL PICK-UP BLOCK (CMS-S76RFS7G)
(for SERVICE) (Including sled motor, spindle motor)
0 T1 1-697-344-11 MAIN TRANS (AEP, UK, AUS, HK, MY)
0 T1 1-697-346-11 MAIN TRANS (CND)
WIFI1 X-2589-576-1 PWB BCO SVX (WiFi module) (for SERVICE)
(See Note 2)
*************************************************************
Note 2: When the WiFi module (Ref. No. WIFI1) is replaced, refer to
“NOTE OF REPLACING THE WiFi MODULE”, “PROCESS-
ING OF REPLACING THE WiFi MODULE” and “CHECK-
ING METHOD OF NETWORK CONNECTION” on page 6.
Note 1: When the WiFi antenna (Ref. No. ANT1) is replaced, refer to
“CHECKING METHOD OF NETWORK CONNECTION” on
page 6.
