Sony MAP-S1 - IC Pin Function Descriptions Continued; Main Board IC503 Pinout Description

MAP-S1
85
Pin No. Pin Name I/O Description
174 D3.3V_SOC - Power supply terminal (+3.3V)
175 RESET_IOEX O Reset signal output to the I/O expander “L”: reset
176
CDM_LOAD_
END_SW
I Loading end detection switch input terminal
