Sony RB1G - Slide Number 13

To Next Page

To Previous Page

RB1G CHASSIS

W600A/ W603A/ W605A/ W607A/ W650A/ W651A/ W653A/

W654A/ W655A/ W656A/W657A/ W658A/ W670A/ W674A

Safety Notes

14. Remove “PWB_HSC” (2 Position Hook)

Remove PWB, HSC pinching and rotating this hook.

PWB,

HSC

CASE

15. Finish

PANEL

ORNAMENT

BARE, SC A

HIR_TE_LW

MOUNT

CASE, SC

(QTT/JAZ/WLT) A

WLAN MODULE

HSC-LW_WWIFI

MOUNT

LID, SC (MMB)

COVER, SC

(MMB)

SCREW +BVTP

3X10 TYPE2 IT-3

HARNESS ASSY
