RB1G CHASSIS

W600A/ W603A/ W605A/ W607A/ W650A/ W651A/ W653A/

W654A/ W655A/ W656A/W657A/ W658A/ W670A/ W674A

SECTION 3

TROUBLESHOOTING

3-1. No Power

Note: For location details, refer to troubleshooting Reference for parts location.

No Power

Check STBY 3.3V

L9101 (B-others)

C9318 (BK*)

Harness

G* Board

Replace

Between G* Board to

B* Board Harness

B* Board

DC/DC converter check

NO POWER: Ayu2 control

Size B* Board Type

(Segment: LW)

OTHERS EUROPE JP

32” BKX BKE BKJ

42” BKX BKE BKJ

Note:

G BOARD : ( N/A FOR THIS MODEL)
