RB1G CHASSIS

W600A/ W603A/ W605A/ W607A/ W650A/ W651A/ W653A/

W654A/ W655A/ W656A/W657A/ W658A/ W670A/ W674A

302

Troubleshooting

3-2-8 LED BLINKING 8x (Software Error)

Note:

(AYU2/Ayu2L) – IC9000

(Brownie)- IC9001

8-time blinking

Check clock signal

@ R8558 (B*-Others)

@ R8617 (BL*)

B* Board NG

CH or AEP destination?

B* Board NG

YES

CI CAM module

B* Board NG

Using CAM Module?

YES

B* Board NG

Size B* Board Type

(Segment: LW)

OTHERS EUROPE JP

24” BLX BLE BLJ

32” BKX/BLX BKE/BLE BKJ/BLJ

42” BKX/BLX BKE/BLE BKJ/BLJ

50” BLX BLE -
