Sony RB1G - 3-10. Network Malfunction: Ethernet (Wired)

To Next Page

To Previous Page

RB1G CHASSIS

W600A/ W603A/ W605A/ W607A/ W650A/ W651A/ W653A/

W654A/ W655A/ W656A/W657A/ W658A/ W670A/ W674A

372

Troubleshooting

3-10. Network Malfunction: Ethernet (Wired)

[Network Set-up]

>[Wired Set-up]

on the TV

Ethernet Cable

Connection Results

Cable Connection

Proxy setting

Connection Results

Local Access

Connection Results

Internet Access

Failed

Wired Set-up

IP address setting

Auto

Check

Local router

DHCP server

Manual

Check IP address

Local router setting

Check cable

B* board

(*)

B* Board

Check LED of

Router/Ether hub

blinking ?

Ethernet

Connector or Trans

Ether PHY

Power

Power, Reset

PHY control

MDIO Interface

AYU2/Ayu2L MDIO I/F

Ether PHY

IC6301

Yes

NG NG

PHY data comm.

RMII Interface

PHY Strap

Configuration

Ether PHY

REFCLK

AYU2/Ayu2L REFCLK

Check Pin 7 , 10

At IC6301

Check Pin 11

At IC6301

Check Pin 16,17

At IC6301

Check Pin

(TX)12,13,

(RX) 8,9,

TX+/-, RX+/-

CHK1

CHK2

CHK3

CHK4

CHK5

Note:

(AYU2/Ayu2L) – IC9000

(Brownie)- IC9001

Size B* Board Type

(Segment: LW)

OTHERS EUROPE JP

24” BLX BLE BLJ

32” BKX/BLX BKE/BLE BKJ/BLJ

42” BKX/BLX BKE/BLE BKJ/BLJ

50” BLX BLE -
