RB1G CHASSIS

W600A/ W603A/ W605A/ W607A/ W650A/ W651A/ W653A/

W654A/ W655A/ W656A/W657A/ W658A/ W670A/ W674A

3-2-7. LED Blinking 7x (Temperature Error)

Troubleshooting

3-2-6. LED Blinking 6x (Backlight Error)

6-time blinking

Check BL_ERR

(JL9112) at

Pin 18 of CN9101

on the B* Board

B* Board

Low

G* board (Others)

High

Symptom

improvement

Change G* Board

(Others)

Panel

For Ayu2(IC9000)

replacement check

related section

Note:

(AYU2) – IC9000

(Brownie)- IC9001

7-time blinking

B* Board

Yes

Panel

Change B* Board,

and Aging a few hours

Setting circumstance

is OK?

Temperature,

Ventilation, etc.

Set to another

location, etc.

Symptom

improvement

Size B* Board Type

(Segment: LW)

OTHERS EUROPE JP

32” BKX BKE BKJ

42” BKX BKE BKJ

Note:

G BOARD : ( N/A FOR THIS MODEL)
