RB1G CHASSIS

W600A/ W603A/ W605A/ W607A/ W650A/ W651A/ W653A/

W654A/ W655A/ W656A/W657A/ W658A/ W670A/ W674A

Size B* Board Type

(Segment: LW)

OTHERS EUROPE JP

24” BKX BKE BKJ

32” BKX BKE BKJ

42” BKX BKE BKJ

201

Troubleshooting

No Picture

Is blue picture

on display?

(Factory SW

is booted)

Yes

Replace

the LVDS FFC

Harness

LCD Panel

(T-CON)

LVDS FFC

Harness

Check

BL_ON at JIG LAND

on the B* Board

BL_ON：H

B*-Board NG

Replace Harness

between G*-Board(n/a)

to B*-Board.

(LS Only)

Replace G*-Board to

B*-Board Harness

BL_ON：L

Change B*-Board

Change G*-Board

or Adaptor (LW)

Check

PANEL_VCC

at JIG LAND

on the B* Board

G*-Board or

Adaptor NG

Yes

PANEL_VCC = +12V

LS(G*-Board): JL9102

LW (Adaptor): JL9301

Symptom

improvement

Symptom

improvement

Symptom

improvement

・

B*-Board is OK.

Check:

Tuner - No Picture

HDMI - No Picture

Ext. Video Input -

No Picture

BL_ON (L or H)

LS (G*-Board): JL9111

LW (Adaptor): JL8205

3-5-18. NO PICTURE: (Except HFR Model)

3-5. No Picture

(*)

Note:

G BOARD :

( N/A FOR THIS MODEL)
