Sony RB1G - Slide Number 306

To Next Page

To Previous Page

RB1G CHASSIS

W600A/ W603A/ W605A/ W607A/ W650A/ W651A/ W653A/

W654A/ W655A/ W656A/W657A/ W658A/ W670A/ W674A

306

Troubleshooting

3-3. No Sound

No Sound

Change the Speaker

Harness

Speaker Harness

Replace

the B* Board

Speaker

Check the

“Speakers setting”

Change to

“TV Speaker”

“Audio System”

“TV Speakers”

Symptom

improvement

Symptom

improvement

No Sound:

Audio

No Sound:

Tuner

No Sound:

HDMI

B* Board

Size B* Board Type

(Segment: LW)

OTHERS EUROPE JP

24” BLX BLE BLJ

32” BKX/BLX BKE/BLE BKJ/BLJ

42” BKX/BLX BKE/BLE BKJ/BLJ

50” BLX BLE -
