RB1G CHASSIS

W600A/ W603A/ W605A/ W607A/ W650A/ W651A/ W653A/

W654A/ W655A/ W656A/W657A/ W658A/ W670A/ W674A

360

Troubleshooting

3-3-9. NO SOUND: MHL

No Sound

Check the picture

Refer to MHL NO PICTURE

Check the settings of

Source equipment

Check R5071, C5071, C5072,

C5059, C5073

Replace NG part

Check Sound by other TV set

which is same model

Inform the designer

of it

Check Source equipment

by Reference TV set

(For example, Samsung TV(UN46ES7000)

, Toshiba TV(42WL863))

or VA-1836

Replace

IC9000

Note:

(AYU2/Ayu2L) –

IC9000

(Brownie)- IC9001

Size B* Board Type

(Segment: LW)

OTHERS EUROPE JP

24” BLX BLE BLJ

32” BKX/BLX BKE/BLE BKJ/BLJ

42” BKX/BLX BKE/BLE BKJ/BLJ

50” BLX BLE -
